Product Overview
Great comfort and extreme stability thanks to radio frequency
• Interference-free RF 3D emitter for long-range 3D synchronization
• RF 3D emitter for EDGETM RF 3D glasses
• Supports IR, DLP-Link, VESA to RF signals
• RF range up to 30 meters (98 ft)
• Compatible with all frequencies up to 240Hz
| Recommended Installation | ||
|---|---|---|
| Number of seats | 1 to 50 | |
| Projector type | All | |
| Screen | White - gain 1.0 / 1.2 /... | |
| Compatible glasses | PixelLight RF 3D glasses | |
| Compatibility | ||
| 3D projectors | ||
| DCI* | Yes | |
| Mono DLP | Yes | |
| 3xDLP | Yes | |
| DILA (JVC™, DreamVision™, Wolf Cinema™) | Yes | |
| SXRD (Sony™, Mitsubishi™...) | Yes | |
| 3xLCD (Epson™, Panasonic™...) | Yes | |
| Flat screen 3DTVs | ||
| Plasma | Yes | |
| LCD / LED 3DTVs | Yes | |
| LCD 3D screens and PCs | Yes | |
| DLP TVs | Yes | |
| 3D sync source | ||
| GPIO (3D Cinema) | Yes (cable optional) | |
| VESA DIN-3 | Yes | |
| BNC | Yes | |
| Jack (Panasonic) | Yes (cable optional) | |
| JRJ45 (Epson) | Yes (optional conversion box)) | |
| 3D Protocols | Reception) | Emission |
| 3D Cinema (IR) | Yes | No |
| HomeCinema 3D(DLP-Link) | Yes | No |
| Universal 3DTV (IR) | Yes | No |
| Universal 3D Computer (IR) | Yes | No |
| PixelLight 3D (RF) | Yes | Yes |
| Bluetooth | No | No |
| Specification | ||
| Power Supply | 5V USB - 12V via VESA | |
| Certification | ||
| ROHS | Yes | |
| CE | Yes | |
| Frame Rates | ||
| 96 Hz HFR & Home Cinema 3D | Yes | |
| 120 Hz Sport HFR & 3D-ReadyTM | Yes | |
| 144 Hz Triple Flash 3D Cinema | Yes | |
| 192 Hz HFR Full Comfort | Yes | |
| 240 Hz | Yes | |
| Dual View Mode | Yes | |
| Qualification | ||
| Panasonic | Yes | |
| Radio frequency | ||
| Frequency | 2.4 Ghz | |
| Power | -20 to+10 dBm | |
| Range | Up to 30m (98 ft) | |
| Approval | Band ISM, Not necessary | |
| Logistics | ||
| Operating temperature | 0°C to 40°C | |
| Storage temperature | -5°C to 50°C | |
| SRelative humidity | 20% to 80% | |
| Relative humidity | 43 x 30 x 70 mm | |
| Product weight | 20 g | |
| Warranty | 1-year | |
| Packaging | ||
| Composition | ||
|
• ActivHub™ RF50 • Update/recharge USB/µUSB cable • VESA-3pin mini DIN cable • BNC cable • Jack cable • User guide |
||
| Accessories (optional) | ||
|
• Manufacturer cables (Mitsubishi) • Conversion box RJ45 Epson/VESA • Power Supply |
||
| Weight and Dimensions | ||
| Packaging dimensions (L x W x H) | 200 x 115 x 75 mm | |
| Packaging weight | 160 g | |
| Order reference | VPES-04100 | |
